Set the X.Modem parameter (Programming Quick Key ) to YES. Access the Installer Menu and choose: 7) Accessories > 1) Add Delete Module > 9) More. > 7) XMODEM. Set the Type field to Xmodem. Programming: Adding the modem to the ProSYS To enable the operation of the Fast Modem the following steps should be performed: 1. Off: Tamper terminals open. Use to connect a tamper switch DIP 2 Not used DIP 3‐4 Dip switches 3 and 4 determine the local standards to which the modem can comply with: DIP 3 DIP 4 Standard OFF OFF CTR 21 ‐ European Union OFF ON FCC ‐ United States ON OFF CAN ‐ Canada ON ON AUS ‐ Australia

Note: The PSTN Fast Modem is connected in parallel to the ProSYS telephone line. The connection to the wall outlet can be from any one of the following options: to the LINE IN (J12) on the modem (Option A) or to the ProSYS phone connection LINE IN (see Option B).ĭIP Switches Settings CONFIG Description DIP 1 Controls the configuration of the tamper terminals On: Tamper terminals shorted. Wire the modem according to Wiring Diagram. Install the fast modem into a box using the supplied 2 screws. When using the Upload/Download software to establish communication with the fast modem you need to select the Fast PSTN Modem option. To enable remote Upload/Download with the fast modem the Upload /Download GSM Enable parameter has to be set to No (Programming Quick Key ).


Communication with fast modem is supported by ProSYS Ver. 7 and above and by Upload/download software ver 3.2.3.6 and above.
